Blanco BLANCOAXON Montage- Und Pflegeanleitung Seite 5

Assembly and care instruction for BLANCO ceramic sinks with a
PuraPlus ® finish – Please read carefully and keep in a safe place
BLANCO brand-name ceramic sinks.
BLANCOAXON
Fine stoneware
Functionality and flexibility are at the forefront of the design of these ceramic sinks.
Please observe the following for assembly, use and care:
1. Please observe the following when attaching fittings.
If additional fittings are to be attached, the designs BLANCOAXON, BLANCODELTA
and BLANCOPRION 9 E all have a breaking point that can be utilised for this purpose.
Please observe the following in order to prevent damage:
1. The breaking point must be
opened before the sink is
inserted into the worktop.
2. Measure the centre of the
breaking point and mark it
on the glazed side.
3. Using a spindle or chisel,
hammer through the middle
of the breaking point from
top to bottom.
(Warning: wear protective
goggles!)
4. Using a hammer or chisel, increase the size of the hole as required
(max. 35 mm diameter).
Never hammer through from the bottom of the glazed side upwards!
2. Please observe the following when attaching the drainage fittings.
A seal is required between the sieve cone and valve imprint for professional
assembly of the drainage fitting.
Use the sealing mass included with the drainage fitting and
proceed as follows:
1. Roll the sealant out to a string and wrap around
the valve cone.
2. Position the cone centrally, press into position and
screw the drainage fitting into place.
3. Trim any excess sealant away neatly
with a knife.
BLANCODELTA
Fine stoneware
BLANCOPRION
Finefireclay
