Quick installation guide IB-1817Ma-C31
1. Installation
Important: During the drive assembly all cabling has to be disconnected from
the computer.
Screw, Screw nut
1. Take out the PCB.
2. Combine the circular notch of the
round M.2 holder with the semi-circular
notch of the M.2 SSD and hold it with
one finger (the thinner side upwards).
Insert your SSD carefully with the
connection side into the M.2 socket
at an angle of about 30° so it fits in
smoothly.
3. Then push the SSD card down
and fix the M.2 nut with the screw as
displayed.
