1) BRIGHTNESS
2) CONTRAST
3) H POSITION
4) V POSITION
5) PHASE
6) PIXEL FREQ.
COLOR
The tone of color can be changed from red-dish white to bluish white.
The individual color components are also user customizable.
* With VOL ▸, go to SUB MENU. After adjusting in SUB MENU, press MENU
to exit.
1) 9300K
2) 7300K
3) 6500K
4) USER
Downloaded from www.Manualslib.com
Adjust the brightness of DSUB ANALOG without affecting
AV's brightness.
Adjust the contrast of DSUB ANALOG without aff ecting
AV's contrast.
Adjust the horizontal position of the image.
Adjust the vertical position of the image.
Remove the noises. When phase value is wrong, the
image has vertical lines especially in 1 dot on and off.
Adjust the sampling frequency of DSUB analog signal.
COLOR
SETUP
The color temperature could be changed based on the LCD
specification.
Change color temperature : Red 42 Green 52 Blue 50
Change color temperature : Red 51 Green 46 Blue 46
Change color temperature : Red 40 Green 54 Blue 54
User customizable. (RED, GREEN, BLUE)
manuals search engine
9300K 7300K 6500K
RED 50 -
GREEN 50 -
BLUE 50 -
USER
+
+
+
