There are no servicable parts inside the device except for the fuse. Maintenance and service operations are
only to be carried out by authorized dealers.

Replacing the fuse

If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Open the fuseholder on the rearpanel with a fitting screwdriver.
Step 2: Remove the old fuse from the fuseholder.
Step 3: Install the new fuse in the fuseholder.
Step 4: Replace the fuseholder in the housing.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device will be damaged, it has to be replaced by a special power supply
cable available at your dealer.
If defective, please dispose of the unusable device in accordance with the current legal regulations.
Should you have further questions, please contact your dealer.

TECHNICAL SPECIFICATIONS

Power supply:
Power consumption:
Smoke-output:
Warm-up time:
Fluid consumption:
Output volume:
Tank capacity:
Dimensions (LxWxH):
Weight:
Please note: Every information is subject to change without prior notice. 03/02 ©
230 V/50 Hz
1000 W
approx. 5 m
approx. 7 min.
approx. 75 ml/min.
approx. 400 m³/min.
1.5 l
435 x 270 x 280 mm
7 kg
