Baofeng UV-5R Serie Bedienungsanleitung Seite 19

Menu Name (Full Name) Setting
17 S-CODE Signal 1[0] |2[1] |3[2] |4[3] |5[4] |6[5] |
Code 7[6] |8[9] |9[8] |10[9] |11[10] |
12[11] |13[12] |14[13] |15[14]
18 SC-REV-Scanner To [0]: Time Operation-scanning
Resume Method Will resume after a fixed time
has passed
CO [1]: Carrier Operation-
Scanning will resume after the
signal received disappears
SE [2]: Search Operation-
Scanning will not resume
automatically
19 PTT-ID – When to OFF [0]: No ID is sent
send the Push-To-
BOT [1]: The selected S-CODE
Talk (PTT-ID)
is sent at the beginning
EOT [2]: The selected S-CODE
is sent at the beginning and
ending
20 PTT-LT-Signal 0-50ms
Code sending
delay
31
Description
Selects 1 of 15 DTMF codes. The DTMF codes
are programmed with computer software and are
up to 5 characters/digits each.
Scanning Resume Method.
When to send PTT-ID
The codes are sent either at the beginning or
ending of a transmission.
PTT-ID Delay (milliseconds)
Menu Name (Full Name) Setting
21 MDF-A-Channel CH [0]: Displays the channel
Mode A Upper LCD number
Display
NAME [1]: Display the channel
name
FREQ [2]: Display programmed
Frequency
22 MDF-B-Channel CH [0]: Displays the channel
Mode B Lower LCD number
Display
NAME [1]: Display the channel
name
FREQ [2]: Display programmed
Frequency
23 BCL- Busy Channel OFF [0] | ON [1]
Lock-out
24 AUTOLK OFF [0] I ON[1]
32
Description
[A] MR/Channel Mode Display Format
Note: Names must be entered using computer
software.
[B] MR/Channel Mode Display Format
Note: Names must be entered using computer
software.
Disables the [PTT] button on a channel that is
already in use. The transceiver will sound a beep
tone and will not transmit if the [PTT] button is
pressed when a channel is already in use.
When OFF the numeric keypad is not
automatically locked after 10 seconds.
When ON the numeric keypad is locked after 10
seconds.
NOTE - To unlock the numeric keypad press and
hold the #/Lock button on the numeric keypad.
