Guntermann & Drunck GmbH
6
Housing Dimensions
(W x H x D in mm)
Electrical Data:
•
•
•
•
Transmission Length:
•
•
•
Maximum resolution: 1600/1280 @ 85 Hz.
With a lower resolution longer ranges are possible.
Frequency transmission bandwith at different cable length and up to a
permitted voltage loss of 3dB:
•
•
•
•
•
•
•
Downloaded from www.Manualslib.com

Technical Data

103 x 36,5 x 107
Power supply : 9V DC
Internal operating voltage: +5V and –5V
Complete current consumption at white picture: 132mA/9V
Current output of the DCDC-converter: 37mA/-5V
Monitor remote, VG38 from 0m up to approx. 50m.
Monitor remote, MC316 from 0m up to approx. 100m.
Monitor local, VG38 or standard monitor cable up to 5m
Monitor local
Monitor remote with 10m VG38:
Monitor remote with 20m VG38:
Monitor remote with 50m VG38:
Monitor remote with 60m VG38:
Monitor remote with 70m MC316:
Monitor remote with 110m MC316:
manuals search engine
Operation Instructions Video-Splitter 2
288MHz
≥ 400MHz
300MHz
220MHz
196MHz
258MHz
189MHz
page 7
plus
