2.3 Connecting with a remote monitor

Connect the extension cord V-KMVL-x or KMC-x (x = length in meter) with the
interface Monitor remote
Connect the other side of the extension cord with the remote monitor (or with
the connecting cable of your monitor).
3
Basiclly the VS-2
illustration shows, what kind of interfaces exist:
„CPU"-side
Connecting
power supply
„monitor"-side
Downloaded from www.Manualslib.com

Interface - Illustration

plus
consists of a PC side an a monitor side. The following
1 2
video amplifying
regulator
4
Interface
local monitor
manuals search engine
Operation Instructions Video-Splitter 2
plus
of the VS-2
.
3
Interface
VGAin
5
Interface
remote monitor
page 5
