After you have set up all connections between the VS-2
(local and remote) and the VGA-port of your computer, please proceed as
follows:
5
Over a regulator
adjusted (remote tuning).
Mode of operation of the regulator:
Turn left (anti-clockwise)
Turn right (clockwise)
Since the needed amplifying depends on various parameter, no guideline can
exactly be given. The best picture can be tuned by appropriate turning of the
regulator.
If you do the installation by yourself, optimize the picture before installing the
cable, since you cannot tune a view the remote monitor at the same time.
Downloaded from www.Manualslib.com

Getting started

Connect the Power Supply 15D3-09MP (1,7 / +9V DC) with the VS-
plus
2 (A green LED on the CPU-side indicates, if a correct power supply
has been established)
Switch on monitor
Switch on CPU

Tuning the amplifiying of the remote monitor

the video amplifiying of the remote monitor can be
Remote
tuning
Lower amplifying (short cable)
higher amplifying (long cable)
