Guntermann & Drunck GmbH
6

Technical Data

Housing Dimensions

(W x H x D in mm)
Electrical Data:
•
Power supply : 9V DC
•
Internal operating voltage: +5V and –5V
•
Complete current consumption at white picture: 132mA/9V
•
Current output of the DCDC-converter: 37mA/-5V
Transmission Length:
•
Monitor remote, VG38 from 0m up to approx. 50m.
•
Monitor remote, MC316 from 0m up to approx. 100m.
•
Monitor local,
Maximum resolution: 1600/1280 @ 85 Hz.
With a lower resolution longer ranges are possible.
Frequency transmission bandwith at different cable length and up to a
permitted voltage loss of 3dB:
•
Monitor local
•
Monitor remote with 10m VG38:
•
Monitor remote with 20m VG38:
•
Monitor remote with 50m VG38:
•
Monitor remote with 60m VG38:
•
Monitor remote with 70m MC316:
•
Monitor remote with 110m MC316:
All manuals and user guides at all-guides.com
103 x 36,5 x 107
VG38 or standard monitor cable up to 5m
≥ 400MHz
page 7
Operation Instructions Video-Splitter 2
288MHz
300MHz
220MHz
196MHz
258MHz
189MHz
plus
