Niko Home Control Gebrauchsanleitung Seite 33

62
2.1.4 Ventilation control
A Press to control the ventilation system. The + and - buttons
appear on the screen.
5 5 5 5 5 5 50 5 5 5 5 5 5 5 5 5 5 5 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
B adjust the speed setting using the + and - buttons.
available speed settings for ventilation control are:
: low (eco-mode)
: medium
: high
: boost (the boost function activates the highest ventilation
setting during a period of time predefined by the installer)
2.1.5 Roll-down shutter control
A Press to control a specific roll-down shutter. The arrow buttons
5 50 5 5 5 5 5 5 5 5 5 5 5 5 5 5 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
appear on the screen.
5 5 5 5 5 5 5 5 5 5 5 5 50 5 5 5 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
B Press the "up" or "down" arrow button to open or close the roll-
down shutter respectively.
When the roll-down shutter is open, only the "down" arrow button
will appear.
When the roll-down shutter is closed, only the "up" arrow button
will appear.
C Press the pause symbol at any time to pause all motion.
5 5 5 5 5 5 5 5 50 5 5 5 5 5 5 5 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
63
