Konfiguration über die Ethernetschnittstelle
Beispiel:
Modbus/TCP to RTU Bridge
MAC address 0080A3A77528
Software version V3.3.0.5 (140827) XPTE
Press Enter for Setup Mode
Model: Device Server Plus+! (Firmware Code:YM)
Modbus/TCP to RTU Bridge Setup
1)
2)
3)
4)
7)
D)efault settings, S)ave, Q)uit without save
Select Command or parameter set (1..7) to change:
Sie können nun Änderungen vornehmen und mit S abspeichern. Nun ist es
unter Verwendung der neuen Netzwerkparameter betriebsbereit.
V1.00
Network/IP Settings:
IP Address .............................................. 192.168.0.1
Default Gateway ................................. --- not set ---
Netmask ................................................. 255.255.255.0
Serial & Mode Settings:
Protocol .................................................. Modbus/RTU,Slave(s) attached
Serial Interface ..................................... 19200,8,E,1,RS485
Modem/Configurable Pin Settings:
CP1 ........................................................... RS485 Output Enable
CP2 ........................................................... Not Used
CP3 ........................................................... Not Used
Advanced Modbus Protocol settings:
Slave Addr/Unit Id Source ............... Modbus/TCP header
Modbus Serial Broadcasts ............... Disabled (Id=0 auto-mapped to 1)
MB/TCP Exception Codes ................ Yes (return 00AH and 00BH)
Char, Message Timeout .................... 00050msec, 05000msec
Security Settings:
SNMP ...................................................... Enabled
SNMP Community Name ................. public
Telnet Setup ......................................... Enabled
TFTP Download ................................... Enabled
Port 77FEh ............................................. Enabled
Web Server ............................................ Enabled
Enhanced Password .......................... Disabled
Port 77F0h ............................................. Enabled
multisys D2-MSMT
