PARTS SUBSTITUTIONS & MODIFICATIONS
Parts substitutions and modifications are authorized TDK Lambda service personnel only. For repairs or modifications, the
instrument must be returned to TDK Lambda service facility.
AC INPUT
CAUTION
Risk of electrical shock and energy hazard.
Disconnecting one power supply line disconnects only
one power supply module. To isolate the unit
completely, disconnect all power supply lines. Terminal
blocks should only be used by professional workers to
connect
AC cables.
ACHTUNG
Spannungsfuehrende Teile - Gefahr durch elektrischen
Schlag order hohe Energieinhalte. Alle Netzstecker der
einzelnen Komponenten bzw. der Einschuebe
muessen
getrennt werden, damit das System "spannungsfrei" ist.
Die Eingangsklemme der Stromversorgung ist nur
innerhalb eines Gesamtsystemes zu verwenden.
ENERGY HAZARD
The main outputs of FPS-S1U units are capable of providing
hazardous energy. Due to hazardous energy level the output
and connections therefore must not be user accessible.
Manufacturer's final equipment must provide protection to
service personnel against inadvertent contact with output
bus bars.
FUSE
There are no fuses in the FPS-S1U rack.
OVERCURRENT PROTECTION
A readily accessible branch circuit over-current protective
device rated 20A max. per each input must be incorporated
in the building wiring.
Überstromschutz
Eine leicht zugängliche Vorsicherung mit 20A max.
pro Eingang muss in der Hausinstallation vorgesehen
werden
ATTENTION
Risque de choc et de danger e'lectriques. Le de'branchement
d'une seule alimenttation stabilise'e ne de'branche
uniquement qu'un module "Alimentation Stabilise'e". Pour
isoler completement le module en cause, il faut de'brancher
toutes les alimentations stabilise'es.
Do not connect FPS-S1U units to mains supply exceeding
the input voltage and frequency rating. The input voltage
and frequency rating is: 100-240V~, 50/60Hz. For safety
reasons, the mains supply voltage fluctuations should not
exceed +/-10% of nominal voltage.
The leakage current of the end use equipment not exceed
3.5mA.
SYMBOLS
CAUTION Risk of Electrical Shock.
Instruction manual symbol. The instrument will be
marked with this symbol when it is necessary for
the user to refer to the instruction manual.
Indicates hazardous voltage.
Indicates ground terminal.
Protective Ground Conductor Terminal
Denotes hazard. An attention to a procedure is called. Not
following the procedure correctly could result in personal injury.
A WARNING sign should not be skipped and all indicated
conditions must be fully understood and met.
Denotes hazard. An attention to a procedure is
called. Not following the procedure correctly could
result in damage to the equipment.
