I/O Panel
1
15
No. Description
1 USB 2.0 Ports (USB_23)
2 VGA Port
3 eSATA Connector***
4 LAN RJ-45 Port*
5 Central / Bass (Orange)
6 Rear Speaker (Black)
7 Line In (Light Blue)
8 Front Speaker (Lime)**
2
14 13
No. Description
3 4
12 11
9 Microphone (Pink)
10 Optical SPDIF Out Port
11 USB 3.0 Ports (USB_01)
12 USB 3.0 Ports (USB3_12)
13 HDMI Port
14 DVI-D Port
15 PS/2 Keyboard/Mouse Port
H87M-ITX
5 7
6 8
10 9
3
