No. Description
1
ATX 12V Power Connector (ATX12V1)
2
2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
3
Clear CMOS Jumper (CLRCMOS1)
4
Chassis Intrusion Header (CI1)
5
ATX Power Connector (ATXPWR1)
6
CPU Fan Connector (CPU_FAN1)
7
USB 3.0 Header (USB3_5_6)
8
USB 2.0 Header (USB10_11)
9
System Panel Header (PANEL1)
10
SATA3 Connector (SATA3_0)
11
SATA3 Connector (SATA3_1)
12
SATA3 Connector (SATA3_2)
13
SATA3 Connector (SATA3_3)
14
Chassis Fan Connector (CHA_FAN1)
15
TPM Header (TPMS1)
16
Front Panel Audio Header (HD_AUDIO1)
