ASPIRADOR DE MANO EN SECO Y HÚMEDO MINI ASPIRAPOLVERE-LIQUIDI RICARICABILE SAS 7.4 LI B3 MINI ASPIRAPOLVERE-LIQUIDI RICARICABILE Istruzioni per l’uso ASPIRADOR MANUAL PARA MOLHADO E SECO Manual de instruções WET & DRY HANDHELD VACUUM CLEANER Operating instructions HANDSTAUBSAUGER NASS UND TROCKEN...
Seite 2
Prima di leggere aprire la pagina con le immagini e prendere confidenza con le diverse funzioni dell’apparecchio. Antes de começar a ler abra na página com as imagens e, de seguida, familiarize-se com todas as funções do aparelho. Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.
Bocchetta per l'aspirazione dei liquidi ▯ Supporto a parete ▯ Materiale di montaggio (2 viti, 2 tasselli) ▯ Alimentatore ▯ Manuale di istruzioni Subito dopo il disimballaggio, controllare l'integrità della fornitura. ■ 2 │ IT │ MT SAS 7.4 LI B3...
Contenitore dello sporco Blocco motore Figura B: Vite Tassello NOTA ► L'apparecchio è stato fornito con batterie scariche. Prima di usare l'appa- recchio per la prima volta, caricare le batterie. SAS 7.4 LI B3 IT │ MT │ 3 ■...
BURGSTRASSE 21 44867 BOCHUM Produttore GERMANY Numero di iscrizione alla camera di commercio: HRB 4598 Modello SAS 7.4 LI B3-1 Tensione d'ingresso 100 ‒ 240 V ~ (corrente alternata) Frequenza corrente alternata 50/60 Hz d'ingresso Tensione di uscita 9,6 V...
Non usare l'aspirapolvere per aspirare prodotti chimici, polvere ► di pietra, gesso, cemento o sostanze analoghe. L'apparecchio non è indicato per materiali infiammabili ed ► esplosivi o liquidi chimici e aggressivi. SAS 7.4 LI B3 IT │ MT │ 5 ■...
Seite 9
Verificare sempre che le aperture di ventilazione non siano ► ostruite. L'ostruzione alla circolazione dell'aria può dare luo- go al surriscaldamento dell'apparecchio e provocare danni. ■ 6 │ IT │ MT SAS 7.4 LI B3...
– Rilasciare il tasto di sbloccaggio in modo che il blocco entri nell'intaglio. Il contenitore dello sporco è ora fissato al blocco motore SAS 7.4 LI B3 IT │ MT │ 7 ■...
5) Le bocchette si possono inserire sui supporti laterali per gli accessori. 6) Inserire l'alimentatore in una presa di rete. ■ 8 │ IT │ MT SAS 7.4 LI B3...
fino alla tacca MAX. 1) Rimuovere l'aspirapolvere portatile dal supporto a parete o, se non si utilizza il supporto a parete , estrarre lo spinotto cavo dalla presa. SAS 7.4 LI B3 IT │ MT │ 9 ■...
Seite 13
3) Per accendere l'apparecchio spingere l'interruttore ON/OFF in avanti. La spia di controllo della carica si accende con luce verde. 4) Dopo l'uso, spingere indietro l'interruttore ON/OFF ■ 10 │ IT │ MT SAS 7.4 LI B3...
8) Pulire l'alloggiamento e le due bocchette con un panno leggermente inumidito. In caso di sporco resistente, versare un po' di detergente delicato sul panno. 9) Asciugare accuratamente tutte le parti prima di riutilizzare o conservare l'apparecchio. SAS 7.4 LI B3 IT │ MT │...
I materiali di imballaggio presentano codici costituiti da abbreviazioni (a) e numeri (b) con il seguente significato: 1–7: materie plastiche, 20–22: Carta e cartone, 80–98: materiali compositi ■ 12 │ IT │ MT SAS 7.4 LI B3...
Il prodotto è destinato esclusivamente all’uso domestico e non a quello commer- ciale. La garanzia decade in caso di impiego improprio o manomissione, uso della forza e interventi non eseguiti dalla nostra filiale di assistenza autorizzata. SAS 7.4 LI B3 IT │ MT ...
Badi che il seguente indirizzo non è quello del servizio di assistenza clienti. Contatti innanzitutto il servizio di assistenza clienti indicato. KOMPERNASS HANDELS GMBH BURGSTRASSE 21 44867 BOCHUM GERMANIA www.kompernass.com ■ 14 │ IT │ MT SAS 7.4 LI B3...
Seite 18
Importador ............. 28 SAS 7.4 LI B3 ...
Suporte de parede ▯ Material de montagem (2 parafusos, 2 buchas) ▯ Fonte de alimentação ▯ Manual de instruções Ao retirar o material da embalagem, verifique se foram fornecidas todas as peças. ■ 16 │ SAS 7.4 LI B3...
Filtro de pó Depósito de resíduos Bloco do motor Figura B: Parafuso Bucha NOTA ► O aparelho é fornecido com acumuladores descarregados. Antes da primeira utilização do aparelho, os acumuladores têm de ser carregados. SAS 7.4 LI B3 │ 17 ■...
KOMPERNASS H. GMBH BURGSTRASSE 21 44867 BOCHUM Fabricante GERMANY Número de registo comercial: HRB 4598 Modelo SAS 7.4 LI B3-1 Tensão de entrada 100 - 240 V ~ (corrente alternada) Frequência da alimentação 50/60 Hz de CA Tensão de saída 9,6 V (corrente contínua)
Seite 22
O aparelho não é adequado para substâncias inflamáveis ► e explosivas ou para líquidos químicos e agressivos. Guarde sempre o aparelho em espaços fechados. Para ► evitar acidentes, guarde o aparelho num local seco após a utilização. SAS 7.4 LI B3 │ 19 ■...
Seite 23
Agarre sempre na ficha para desligar o aparelho da alimen- ► tação elétrica. Certifique-se de que o aspirador manual não é colocado ► perto de aquecedores, fornos ou outros aparelhos ou super- fícies aquecidos. ■ 20 │ SAS 7.4 LI B3...
– Solte o botão de desbloqueio , para que o bloqueio encaixe no entalhe. O depósito de resíduos está agora fixo no bloco do motor SAS 7.4 LI B3 │ 21 ■...
4) Coloque as buchas nos furos e aparafuse o suporte de parede a ajuda dos parafusos 5) Pode colocar os bocais no suporte de acessórios lateral. 6) Insira a fonte de alimentação numa tomada. ■ 22 │ SAS 7.4 LI B3...
Aspire líquido, no máximo até que o conteúdo do depósito de residuos atinja a marcação MAX. 1) Retire o aspirador manual do suporte de parede ou, caso não utilize o suporte de parede , retire a ficha fêmea da entrada. SAS 7.4 LI B3 │ 23 ■...
Seite 27
3) Para ligar o aparelho, desloque o interruptor Ligar/Desligar para a frente. A luz de controlo de carregamento acende na cor verde. 4) Após a utilização, desloque o interruptor Ligar/Desligar para trás. ■ 24 │ SAS 7.4 LI B3...
8) Limpe o corpo e os dois bocais com um pano ligeiramente humedecido. Em caso de sujidade resistente, aplique um detergente suave no pano. 9) Seque bem todas as peças antes de utilizar novamente ou armazenar o aparelho. SAS 7.4 LI B3 │ 25...
Tenha em atenção a marcação nos diversos materiais de embalagem e separe-os convenientemente. Os materiais de embalagem estão identificados com abrevia- turas (a) e algarismos (b), com os seguintes significados: 1–7: plásticos, 20–22: papel e cartão, 80–98: compostos ■ 26 │ SAS 7.4 LI B3...
O produto foi concebido apenas para uso privado e não para uso comercial. A garantia extingue-se em caso de utilização incorreta, uso de força e intervenções que não tenham sido efetuadas pela nossa Filial de Assistência Técnica autorizada. SAS 7.4 LI B3 │...
Por favor, observe que a seguinte morada não é a morada do Serviço de Assis- tência Técnica. Primeiro entre em contacto com o Serviço de Assistência Técnica. KOMPERNASS HANDELS GMBH BURGSTRASSE 21 44867 BOCHUM ALEMANHA www.kompernass.com ■ 28 │ SAS 7.4 LI B3...
Seite 32
Importer ............. . . 42 SAS 7.4 LI B3 GB │...
Dust filter bag Dust filter Dirt container Motor unit Figure B: Screw Wall plug NOTE ► This appliance is supplied with non-charged batteries. The batteries must be charged before first use. SAS 7.4 LI B3 GB │ MT │ 31 ■...
Mains adapter KOMPERNASS H. GMBH BURGSTRASSE 21 44867 BOCHUM Manufacturers GERMANY Commercial register number: HRB 4598 Model SAS 7.4 LI B3-1 Input voltage 100 ‒ 240 V ~ (AC) Input AC frequency 50/60 Hz Output voltage 9.6 V (DC) Output current 0.5 A...
Seite 36
This appliance is not suitable for use with inflammable and ► explosive substances or chemical and aggressive liquids. Always store the appliance indoors. To prevent accidents, ► keep the appliance in a dry location when not in use. SAS 7.4 LI B3 GB │ MT │ 33 ■...
Seite 37
Always grip the power plug to disconnect the appliance ► from the power supply. Always be sure to keep the handheld vacuum cleaner away ► from heating elements, ovens or other heated appliances and surfaces. ■ 34 │ GB │ MT SAS 7.4 LI B3...
– Let go of the release button so that the restraint engages in the recess. The dirt container is now firmly seated on the motor unit SAS 7.4 LI B3 GB │ MT │ 35 ■...
firmly into place using the screws 5) You can place the nozzles on the accessories holder on the side. 6) Connect the mains adapter to a mains power socket. ■ 36 │ GB │ MT SAS 7.4 LI B3...
2) If required, place the appropriate nozzle in the suction opening: – the crevice nozzle , to clean narrow and difficult to reach locations. – the wet suction nozzle to vacuum up liquids. SAS 7.4 LI B3 GB │ MT │ 37 ■...
Seite 41
Place the handheld vacuum cleaner in the wall bracket and start the charging process once the vacuum power has become noticeably weaker and the charge indicator lamp flashes green. ■ 38 │ GB │ MT SAS 7.4 LI B3...
8) Clean the housing and both nozzles with a lightly moistened cloth. For stubborn soiling use a mild detergent on the cloth. 9) Dry all parts thoroughly before using the appliance again or storing it. SAS 7.4 LI B3 GB │ MT ...
Note the labelling on the packaging and separate the packaging material components for disposal if necessary. The packaging material is labelled with abbreviations (a) and numbers (b) with the following meanings: 1–7: Plastics, 20–22: Paper and cardboard, 80–98: Composites ■ 40 │ GB │ MT SAS 7.4 LI B3...
The warranty shall be deemed void in cases of misuse or improper handling, use of force and modifications / repairs which have not been carried out by one of our authorised Service centres. SAS 7.4 LI B3 GB │ MT ...
Please note that the following address is not the service address. Please use the service address provided in the operating instructions. KOMPERNASS HANDELS GMBH BURGSTRASSE 21 44867 BOCHUM GERMANY www.kompernass.com ■ 42 │ GB │ MT SAS 7.4 LI B3...
Seite 46
Importeur ............. . 56 SAS 7.4 LI B3 DE │...
Handstaubsauger ▯ Fugendüse ▯ Nasssaugdüse ▯ Wandhalter ▯ Montagematerial (2 Schrauben, 2 Dübel) ▯ Netzteil ▯ Bedienungsanleitung Kontrollieren Sie direkt nach dem Auspacken den Lieferumfang auf Vollständigkeit. ■ 44 │ DE │ AT │ CH SAS 7.4 LI B3...
Abbildung B: Schraube Dübel HINWEIS ► Das Gerät wird mit nicht geladenen Akkus geliefert. Vor dem ersten Ge- brauch des Gerätes sind die Akkus zunächst zu laden. SAS 7.4 LI B3 DE │ AT │ CH │ 45 ■...
(2 x 3,7 V Lithium-Ionen-Akku) Netzteil KOMPERNASS H. GMBH BURGSTRASSE 21 44867 BOCHUM Hersteller GERMANY Handelsregisternummer: HRB 4598 Modell SAS 7.4 LI B3-1 Eingangsspannung 100 ‒ 240 V ~ (Wechselstrom) Eingangswechsel stromfrequenz 50/60 Hz Ausgangsspannung 9,6 V (Gleichstrom) Ausgangsstrom 0,5 A...
Seite 50
Flüssigkeiten geeignet. Lagern Sie das Gerät immer in geschlossenen Räumen. Um ► Unfälle zu verhindern, bewahren Sie das Gerät nach Gebrauch an einem trockenen Ort auf. SAS 7.4 LI B3 DE │ AT │ CH │ 47...
Seite 51
Fassen Sie immer den Netzstecker an, um das Gerät von der ► Stromversorgung zu trennen. Achten Sie unbedingt darauf, dass Sie den Handstaub- ► sauger nicht neben Heizkörpern, Backöfen oder anderen erhitzten Geräten oder Flächen abstellen. ■ 48 │ DE │ AT │ CH SAS 7.4 LI B3...
Schmutzbehälter auf den Motorblock – Lassen Sie die Entriegelungstaste los, so dass die Verriegelung in die Aus- sparung greift. Der Schmutzbehälter sitzt nun fest auf dem Motorblock SAS 7.4 LI B3 DE │ AT │ CH │ 49 ■...
Löcher und schrauben Sie den Wandhalter mit Hilfe der Schrauben fest. 5) Sie können die Düsen auf die seitlichen Zubehörhalter aufstecken. 6) Stecken Sie das Netzteil in eine Netzsteckdose ein. ■ 50 │ DE │ AT │ CH SAS 7.4 LI B3...
MAX-Markierung gefüllt ist. 1) Nehmen Sie den Handstaubsauger von dem Wandhalter herunter, oder, wenn Sie den Wandhalter nicht benutzen, ziehen Sie den Hohlstecker aus der Buchse. SAS 7.4 LI B3 DE │ AT │ CH │ 51 ■...
Seite 55
Flüssigkeit austritt: 3) Um das Gerät einzuschalten, schieben Sie den Ein-/Ausschalter nach vorne. Die Ladekontrollleuchte leuchtet grün auf. 4) Nach Gebrauch schieben Sie den Ein-/Ausschalter nach hinten. ■ 52 │ DE │ AT │ CH SAS 7.4 LI B3...
Tuch. Bei hartnäckigen Verschmutzungen geben Sie ein mildes Reinigungsmittel auf das Tuch. 9) Trocknen Sie alle Teile gut ab, bevor Sie das Gerät wieder verwenden oder verstauen. SAS 7.4 LI B3 DE │ AT │ CH │ 53...
Sie diese gegebenenfalls gesondert. Die Verpackungsmaterialien sind gekennzeichnet mit Abkürzungen (a) und Ziffern (b) mit folgender Bedeu- tung: 1–7: Kunststoffe, 20–22: Papier und Pappe, 80–98: Verbundstoffe ■ 54 │ DE │ AT │ CH SAS 7.4 LI B3...
Das Produkt ist nur für den privaten und nicht für den gewerblichen Gebrauch bestimmt. Bei missbräuchlicher und unsachgemäßer Behandlung, Gewaltanwen- dung und bei Eingriffen, die nicht von unserer autorisierten Serviceniederlassung vorgenommen wurden, erlischt die Garantie. SAS 7.4 LI B3 DE │ AT │ CH │...
IAN 328625_2001 Importeur Bitte beachten Sie, dass die folgende Anschrift keine Serviceanschrift ist. Kontaktieren Sie zunächst die benannte Servicestelle. KOMPERNASS HANDELS GMBH BURGSTRASSE 21 44867 BOCHUM DEUTSCHLAND www.kompernass.com ■ 56 │ DE │ AT │ CH SAS 7.4 LI B3...
Seite 60
KOMPERNASS HANDELS GMBH BURGSTRASSE 21 44867 BOCHUM GERMANY www.kompernass.com Versione delle informazioni · Estado das informações Last Information Update · Stand der Informationen: 05 / 2020 · Ident.-No.: SAS7.4LIB3-042020-1 IAN 328625_2001...
