Using Sparklike Handheld Lcd Screen - sparklike HANDHELD Kurzhandbuch

9. USING SPARKLIKE HANDHELD LCD SCREEN

1. When the ON/OFF button is switched ON, Sparklike Handheld will perform a self
test where it checks itself for errors.
2. The screen will automatically change when all is tested OK
3. The first fixed screen after start up is a device information screen.
4. This screen will be important when communicating with the manufacturer. This screen will be important when communicating with the manufacturer.
5. . The information screen shows:
• Revision of the device
• Last calibration date
• Current time
• Battery charge status
6. Device is now ready to use
7. When the button is pressed for the first time after start up, the measurement result When the button is pressed for the first time after start up, the measurement result
will show.
8. The current time and battery charge status can be seen on the screen.
9. It will also indicate that the measurement has not been logged. (see: How to create
a log file)
10. HOW TO CREATE A LOG FILE
1. From the main menu scroll, by turning the encoder button, to the LOG ON/OFF
menu.
2. Select this by pressing the encoder button once.
3. The next screen shows that the logging is to be started.
4. The device will suggest the following free log name (number) available. If the
suggested number is OK, simply press the encoder button to confirm.
5. By turning the encoder button the number of the log file can be changed. One click
will increase or decrease the number with one.
6. When measuring a text is displayed showing that the logging mode is on and it will
also display the log file number. also display the log file number. also display the log file number. also display the log file number.
11. HOW TO ERASE THE LAST LOGGED FILE 11. HOW TO ERASE THE LAST LOGGED FILE 11. HOW TO ERASE THE LAST LOGGED FILE 11. HOW TO ERASE THE LAST LOGGED FILE
When the log mode is on and a measurement has been taken but the operator feels that
the measurement was an error measurement, it is possible to erase this measurement.
This is done to prevent faulty log files on your computer.
If the measurement is not satisfying:
1. Press down the encoder button
and keep it pressed down for at
least 2 sec.
2. The log value will be deleted
permanently.
