sparklike HANDHELD Kurzhandbuch Seite 4

3. HOW TO USE SPARKLIKE HANDHELD AND STARTING UP
FOR THE FIRST TIME
1. Open the battery hatch
2. Insert the battery
3. Connect it to the battery socket Connect it to the battery socket
4. Turn on the device from the ON/ Turn on the device from the ON/
OFF switch
5. Device settings will show on the Device settings will show on the
screen
6. Register your device to activate
sparklike.com/
the device at
register
7. The device is ready for use
4. HOW TO USE THE SPARKLIKE HANDHELD ENCODER BUTTON
Press down to:
1. Enter MENU
2. Confirm a
selection
5. IN BRIEF, FACTORS TO CONSIDER WHEN MEASURING
Factors affecting the optics:
• Coloured glass
• Tinted glass (minimal effect)
• Strong background light
measurement (against the sun or
other source)
• Dirt on the glass (minimal effect)
• Dirt on the front optical fibre
• Mistreated front optical fibre or
electrode
Factors making it easier for the spark to
"jump":
• High argon fills
• Metallic coating on surface 3
• Thin glass (6mm or less)
• Thin air space (20mm or less)
• Metallic or other conductor on
surface 3, such as low-e coating
• Metallic spacer bar
1
2, 3 2, 3
5 5 5 5
Turn to:
3. Scroll in the
MENU
4. Name a log
file
Factors affecting the spark:
• Thick glass (over 6 mm)
• Plastic films on glass 1 (laminated
glass, coatings, etc.)
• Metallic films on glass 1
• Metallic components in glass 1
• Low Argon fill (less than 80%)
• Wide spacer (over 20mm)
• Electrode is not in contact with the
glass surface
• Handheld is not evenly pressed
against the glass
• Non-metallic spacers
Correct conditions:
• Stable dark background light
• Hand unit NOT moved during
measurement
4 4
7 7 7
NOTE! READ ALL NOTE! READ ALL NOTE! READ ALL NOTE! READ ALL
THE WARNINGS THE WARNINGS
BEFORE THE
DEVICE IS TAKEN DEVICE IS TAKEN
INTO USE
