TLR 22T 4.0 Montageanleitung Seite 76

TLR5931
TLR232038
TLR5931
LOSA6201
TLR231068
TLR5962
Part # English
TLR234093 Rear Shock Tower, Stiffezel
Laydown: 22T 4.0
TLR235008 Flat Head Screws, M3 x 6mm
(10)
TLR237000 5 x 8 x 2.5mm Bearings (2)
TLR2933 Rear Hex, Std Width, Alum:
22SCT
TLR2947 Tungsten Carbide Diff Balls,
2mm (6)
TLR2951 Tungsten Carbide Diff Balls,
3/32mm (14) 22/T/SCT
TLR2952 Silicone Diff Grease, 8cc: 22
TLR2953 Diff Gear, 51T: 22
TLR2954 Drive Rings (2): 22
TLR2955 Outdrive Set: 22
TLR2958 Diff Through Screw & Nut: 22
TLR2963 Layshaft & Spacer: 22
TLR2972 Driveshaft Rebuild Kit: All 22
TLR336000 4mm Aluminum Serrated
Lock Nuts, Black (6)
76 76
Downloaded from www.Manualslib.com
TLR6312
TLR5962
TLR232037
TLR6352
TLR5962
TLR5963
TLR5908
Deutsch
Heckstoßdämpferbrücke,
Stiffezel Laydown: 22T 4.0
TLR: Flachkopfschrauben, M3
x 6mm (10)
TLR 5 x 8 x 2.5mm Lager (2)
Hinterer Sechskant,
Standardbreite, Aluminum,
22SCT
TLR Tungsten Carbide Kugeln,
2mm (6)
TLR Tungsten Carbite Kugel
3/32 (14)
TLR Differentialfett/8cc: 22
TLR Diff-Zahnrad 51Z: 22
TLR Gleitringe Diff: 22
TLR Antriebsklauen Set: 22
TLR Spannschraube mit
Mutter: 22
TLR Hauptwelle mit
Distanzring: 22
Antriebswellen Rebuild Kit:
All 22
TLR 4mm Aluminium
Stopmutter mit Flanch
Schwarz 6St.
manuals search engine
TLR232066
TLR232035
TLR2966
TLR6932
TLR2963
TLR6932
Français Italiano
Support d'amortisseur, Torre ammortizzatore
Stiffezel Laydown : 22T 4.0 posteriore Stiffezel, Laydown:
22T 4.0
Vis à tête fraisée M3 x 6mm Viti a testa piatta M3 x 6mm
(10) (10)
Roulements 5 x 8 x 2.5mm 5 x 8 x 2.5mm cuscinetti (2)
(2)
22SCT - Écrou hex AR, largeur Dado posteriore, larghezza
standard, aluminium standard, alluminio, 22SCT
Billes de différentiel en Sfere diff. al carburo di
carbure de tungstène, 2mm tungsteno, 2mm (6)
(6)
22/T/SCT - Bille de différentiel Sfere diff. al carburo di
en carbure de tungstène, tungsteno, 3/32mm (14)
3/32 (14) 22/T/SCT
22 - Graisse silicone pour Grasso silicone diff., 8cc: 22
diff, 8cc
22 - Couronne de diff 51T Ingranaggio differenziale,
51T: 22
22 - Plateau de différentiel Anelli trasmissione (2): 22
(2)
22 - Noix de sortie de diff Set trascinatore: 22
22 - Vis et écrou de serrage Viti passanti diff. & dadi: 22
du diff
22 - Arbre de slipper avec Albero secondario &
entretoise distanziale: 22
22 - Kit de réparation pour Kit ricostruzione trasmissione:
arbre de transmission tutti i modelli 22
Ecrou auto-freiné épaulé M4, Dado autobloccante
aluminium, noir (6) seghettato 4mm, nero (6)
TLR232027
TLR232007
TLR232011
TLR232007
TLR232027
TLR6932
TLR2966
TLR6932
LOSA6943
TLR5963
TLR5962
Español
Torre Amortiguador Trasero
Stiffezel Laydown : 22T 4.0
Tornillo cónico 3 x 6mm (10)
Rodamientos 5x8x2.5mm (2)
Hexágono trasero, Estándar
Aluminio, 22SCT
Bolas axial carburo de
tungsteno 2mm (6)
Bolas diferencial carburo de
tungsteno 3/32" (14) 22/T/
SCT
Grasa silicona diferencial,
8cc: 22
Corona diferencial 51T: 22
Aros de impulsión (2): 22
Vasos diferencial: 22
Tornillo diferencial y tuerca:
22
Eje transmisión y espaciador:
22
Kit para reconstruir el árbol
transmisión: Todos 22
Tuercas 4mm aluminio con
bloqueo, negras (6)
TLR232066
TLR232035
TLR5909
