STEP 4 Reattach the freezer door
Untitled-3 53
Downloaded from www.Manualslib.com
10
9
10
9
manuals search engine
1. Use a flat-head screwdriver to remove
the screw cap. Then, insert the screw
cap in the opposite side.
CAUTION
To prevent physical damage, use caution
when removing the screw cap.
2. Lay down the refrigerator with care.
Then, remove the screws from the
levelling leg (9) and the bottom hinge
(10).
3. Use a 11 mm wrench to remove the
hinge shaft from the bottom hinge.
Then, insert the auto closer guard as
shown.
4. Insert the bottom hinge (10) in the
opposite side. Then, insert the levelling
leg (9).
5. Insert the freezer door and fit into
the bottom hinge. Then, stand the
refrigerator with care.
English 53
