This symbol indicates instructions or notes regarding safety, to which special attention must be paid.
i
This symbol indicates useful information for the correct functioning of the product.

1. General safety precautions

This assembly and installation manual is intended for qualified personnel only.
Read the instructions carefully before installing the product.
Bad installation could be dangerous.
Use original spare parts only for repairs or replacements of products.
The packaging materials (plastic, polystyrene, etc.) should not be discarded in the environment or left within reach of children, as these are a potential source of danger.
The PAM30 door frame system complies with the essential requirements of the following standards:
EN 16005 European Standard - Safety in use of power operated pedestrian door sets
Standard DIN 18650-1 - Standard DIN 18650-2
Drawings of all standard typologies are available in graphic format for CAD environments (dwg) and image format (pdf) at http://www.ditecentrematic.com/download.
2. Operating instructions
The tests carried out in the laboratory and onsite indicate a maximum load of the door wing of 120 kg.
In the sections below, the used formulas take into account the following standard criteria:
- the PLmax door width is considered to be between the uprights of the fixed doors and/or the frame. The effective passage opening has a tolerance of ±20 mm.
- for every type of door, the reference dimension of the automation is indicated (LT).
3. Entrance/exit door frame – Ditec PAM30 Series
Sliding door made with EN AW 6060 T5 (UNI 9006/1) aluminium alloy extruded profiles
- 30 mm size
- suitable for DITEC automated installations, with special devices that guarantee accident prevention
- surface finish with powder coating (polyester powder in RAL colours- Qualicoat) or anodising (EURAS finishes - Qualanod).
The profile series is equipped to house 8, 10, 22 mm thick glass provided for safe anchoring of the glass and correct adjustment during installation. The system also allows maintenance to be carried
out easily if glasses are accidentally damaged or broken.
The door frame is equipped with special EPDM gaskets for the hermetic vertical stop with brush-type seals in the openable horizontal perimeters which give the system optimal temperature and
sound proofing performances.
The door frames are designed in a wide range of coded typologies to allow customers to select a solution that suits the type of installation according to the specifications in the Technical Manuals.
The PAM30 series consists of profiles (uprights and crosspieces) with sturdy sections which can be used to create all the typologies Standard with Overlight.
