CONNECTING THE BATTERY TESTER
1- Make sure that the area is well ventilated before performing a test.
2- Tester for 6 V and 12 V batteries.
3- Before running a test on the battery, ensure that the ignition and the consumers are switched off. Close all doors
and the boot.
4- Make sure that the battery connections are clean. If necessary, clean them with a wire brush.
Any presence of oxidation between the tester terminals and the battery connectors or between the battery
connectors and the battery terminals reduces the effectiveness of the tester.
5- Connect the negative (black) terminal to the negative terminal of the battery. Connect the positive terminal (red) to
the positive terminal of the battery.
BATTERY TEST - Reaction of the tester after 10 seconds of charging
CHARGING TEST
Batterie OK (green line)
Low or defective battery (yellow line)
Low battery or battery to be replaced (red line)
START TEST
1. Make sure all vehicle consumers are switched off (lights, air conditioning, radio etc.).
2. Start the engine, one of these two results is displayed:
Examples
The indicator displays a voltage below 9.6 V
The indicator shows a voltage higher than 9.6 V
ALTERNATOR TEST
1. Make sure that all vehicle consumers are switched off (lights, air conditioning, radio etc.).
2. Start the engine.
3. Run the engine between 1200 and 1500 rpm.
4. Read the result :
Results displayed
The indicator is beyond
the OK zone
Green line «OK»
Red line «BAD»
6
TBP 100 TBP 100
The battery is operational.
The battery is either defective or discharged. Recharge the
battery to maximum and test again. If the result is the same,
replace the battery
A problem at the cell level is observed (short circuit.....). Replace
the battery. Or the battery is nearing the end of its life. Replace-
ment required.
The starting voltage is not correct. The battery must be replaced.
The starting voltage is normal.
Examples
High starting voltage when the test is
performed with the engine at idle
Normal starting voltage when the test
is performed with the engine at idle
Low starting voltage when the test is
performed with the engine at idle

BATTERY STATUS

Analysis
Analysis
Check that the connections are good. If eve-
rything is properly connected, replace the
alternator.
No problem detected. Normal operation of the
alternator.
The alternator does not provide enough power to
the battery. Check the alternator belts, and make
sure the alternator is running when the engine is
running. If the belts slip or are broken, replace
them and re-test. Check the connection between
the alternator and the battery. If the connection
is bad, clean or replace the cable and re-test. If
the alternator belts and connection are in good
condition, replace the alternator.
