Specifications

Analog Connections
Input (2) 3-pin block connector (Active Balanced)
Output (2) 3-pin block connector (Impedance Balanced)
Mobile (1) TRRS 3.5 mm (1/8")
USB Connections
(1) USB 2.0, Type B
Single port carries 2 input and 2 output channels (Summed mono)
Network Connections (Dante Digital Audio)
(1) RJ45
10 Dante input channels, 2 output channels
Polarity
Non-inverting, any input to any output
Power Requirements
802.3 at Type 2 (PoE Plus), Class 4
Power Consumption
17.5 W, maximum
Weight
1710 g (3.8 lbs)
Dimensions
H x W x D
4 x 21 x 22.6 cm (1.6 x 8.3 x 8.9 in.)
control application
HTML5 Browser-based
Operating Temperature Range
−6.7°C (20°F) to 50°C (122°F)
Storage Temperature Range
−29°C (-20°F) to 74°C (165°F)
Thermal Power Dissipation
Maximum 17.5 W (60 BTU/hr)
typical 14.6 W (50 BTU/hr)
Audio
Frequency Response
+1, -1.5 dB
20 to 20,000 Hz
Dante Digital Audio
Sampling Rate 48 kHz
Bit Depth 24
Downloaded from www.Manualslib.com
TCP/UDP Protocol
udp SNMP
udp PTP
†
udp Custom
udp Dante
udp Dante
udp mDNS
†
udp Dante
udp Dante
udp Dante
manuals search engine
Description
Used by Dante
Dante clocking
Required for packet bridge
Dante audio
Dante audio routing
Used by Dante
Dante Control and Monitoring
Dante Controller
Used by Dante
USB Audio
Sampling Rate
Bit Depth
Latency
Does not include Dante latency
Analog Connections (Block Connectors)
Dynamic Range
20 Hz to 20 kHz, A-weighted, typical
Analog-to-Dante
Dante-to-Analog
Equivalent Input Noise
20 Hz to 20 kHz, A-weighted, input terminated with 150Ω
Line -86 dBV
Aux -98 dBV
Total Harmonic Distortion
@ 1 kHz, 0 dBV Input, 0 dB analog gain
<0.05%
Common Mode Rejection Ratio
150Ω balanced source @ 1 kHz
>50 dB
Input Impedance
9.6 kΩ
Input Clipping Level
Line +27 dBV
Aux +15 dBV
Output Impedance
80 Ω
Output Clipping Level
Line +20 dBV
Aux +0 dBV
Mic -26 dBV
11
44.1, 48 kHz
16, 24
Dante 1-8 in to Dante out (AEC enabled)
Dante 1-8 in to Dante out (AEC disabled)
Dante 9-10 in to Dante out
Analog in to Analog out
113 dB
117 dB
12.5 ms
5.8 ms
1.8 ms
2.2 ms
