Component Checklist
IMPORTANT: Ensure all parts according to the component checklist have been received prior to installation. If any parts are
missing or faulty, visit www.tripplite.com/support for service.
Wall Plate (x1)
Left Adapter Bracket
Right Adapter Bracket
Security Bar (x1)
(x1)
(x1)
Hex Key (x1)
Left End Cap (x1)
Right End Cap (x1)
End Cap Screws (x4)
Combo Lock (x1)
M5 x 14 (x4)
M6 x 14 (x4)
M6 x 30 (x4)
M8 x 30 (x4)
M8 x 50 (x4)
Washer (x4)
Small
Big
Spacer (x8)
Spacer (x8)
Anchor Bolt (x4)
Concrete Anchor
20 mm Washer
(x4)
(x4)
Installation
Assemble the Wall Plate
1
End Cap
Screws
3
