Dear PowerBox pilot,
We are delighted that you have chosen a power supply system from the Po-
werPak series. These high-quality energy storage units combine maximum
power density and security in a rugged, compact case. PowerPaks are very
flexible: thanks to the mounting frame supplied as standard, they are easy to
install, and can be swapped between models.
The PowerPaks 2.5X2 are available in two versions: ECO and PRO. The two
variants differ only in the charging technology – the performance of the cells
is always the same. The PRO version features integral charging circuitry and
a voltage monitor, whereas the ECO version is charged using a conventional
Li-Ion charger. Balancers are standard in both versions.
The self-discharge feature originally fitted is to be discontinued as of Winter
2018, this function is now handled by the supplied BattLife Guard!
We hope you have years of pleasure and success with your PowerPak.
FEATURES:
integral charge / security electronics (PRO version)

can be charged using mains PSU or 12 V adapter (PRO version)

integral voltage monitor using external LED (PRO version)

Packs assembled using the latest generation of high-current

Li-Ion batteries
two different versions: ECO and PRO

two different output voltages: 8.4 V and 12.6 V

maximum discharge current 30 A

for use as receiver power supplies or turbine batteries

integral balancer

integral charge socket

rugged case protects cells from external influences

Packs are held securely in the standard mounting frame with

quick-release latch
Batteries can remain in the model for charging

easy, swift battery swapping

economical cell exchange service
