General notes
GB
Correct position of the vial (Ø 24 mm):
Insertion of the adapter for 16 mm cells on the sample chamber

Replacement of batteries:

(F) instrument back
CAUTION:
To ensure that the instrument is water proof:
• seal ring (E) must be in position
battery compartment cover (B) must be fixed with the four screws
•
If the batteries are removed for more than one minute the date and time menu starts auto-
matically when the photometer is switched on the next time.
AL200_8 03/2018
manuals search engine
(D) batteries
(C) notch for
data transfer
(B) battery compart-
ment cover
(E) seal ring
(A) screw
IR
:
