Table of contents

Scope of delivery

● Remote control transmitter
● Remote control receiver
●
Crystal pair
● Operating manual

Technical Data

Transmitter
Frequency range:
Modulation:
Channel number:
Operating voltage:
Dimensions (WxHxD):
Weight (including
rechargeable battery):
CARSON 6 Channel Transmitter 501000
Scope of delivery................................................................... 3
Technical Data ....................................................................... 3
Safety instructions
a) General information ......................................................
b) Operation ......................................................................
c) Information about batteries/rechargeable batteries ......
Transmitter controls .............................................................. 6
a) Display ..........................................................................
b) Controls .........................................................................
Getting started with the transmitter .................................... 9
Commissioning the Receiver ............................................. 10
Model-specific Functions ................................................... 11
a) Model A .......................................................................
b) Model V .......................................................................
c) Model H .......................................................................
d) Model C .......................................................................
e) Model C1 .....................................................................
Changing the crystal ........................................................... 13
Maintenance and care ......................................................... 13
Disposal................................................................................ 14
Troubleshooting .................................................................. 14
35 MHz
FM/PPM
6
9.6 - 12 V/DC
via 8 mignon batteries or
rechargeable batteries
170 x 245 x 90 mm
appr. 640 g
4
4
5
8
8
11
11
12
12
13
Features
In this six-channel remote control set, you own a radio remote
control system that is ideally suited for primarily model helico-
pters and model airplanes. However, if required, you can also
use it to control model vehicles and model ships.
Its proportional control channels allow six driving, steering and
control functions to be remotely controlled independently from
one another.
The ergonomic housing fits comfortably into your hand and
allows for an easy and safe operation of the model and the
transmitter.
Operation requires 8 Mignon batteries (e.g. Carson item no.:
609000, pack of 4, 2300 mAh, order 2 x) or accumulators for
the transmitter as well as 4 mignon batteries (e.g. Carson order
number: 609000, pack of 4, 2300 mAh, order 1 x) or rechargea-
ble batteries for the transmitter.
Receiver
Frequency range:
Modulation:
Channel number:
Connector system:
Operating voltage:
Dimensions (WxHxD):
Weight:
35 MHz
FM/PPM
6
Futaba/Graupner JR
4.8 - 6 V/DC
via 4 mignon batteries or
rechargeable batteries
39 x 24 x 22 mm
ca. 14 g
