1
EN60669-1/ EN60669-2-1
18.51.8.230.0300
U
(110...230)V AC (50/ 60 Hz)
N
www.findernet.com
U
: 96 V AC
min
18.51
U
: 253 V AC
max
P: 1.5 VA (50Hz)/1 W
1 NO (SPST−NO)
10 A 250 V AC
AC1
2500 VA
AC15
450 VA
(230 V)
1000 W
(230 V)
350 W
CFL–LED (230 V)
300 W
(–10...+50)°C
IP40
8 mm
Max
:
2.5 mm
2
14 AWG
4
4a
4b
4c
1
2
IB1851001 - 04/13
1a
1b
1c
60 mm
60 mm
5
LUX
1
2
L
2
6
N
4 m
8 m
3
6a
A
B
C
ENGLISH
7
1
18.51 PIR MOVEMENT AND PRESENCE DETECTOR
1
INSTALLATION
1a
Suspended ceiling mounting
1b
Recess mounting
2
1c
Surface mounting
2
WIRING DIAGRAM
3
SETTINGS
3
A: turn -off delay setting (I=12s; II=3 min; III=15 min; IV= 35 min)
B: sensitivity setting: Adjust sensitivity to suit the location and avoid
false triggering
C: ambient light intervention threshold setting
(I=1lx; II=10lx; III=500lx; IV= always ON (
4
TERMINAL PUSH -IN CONNECTION
4
4a
Connection - solid cable or with ferrules
4b
Connection - stranded cable
4c
Disconnection
5
FUNCTION CHART
1
Detection of movement
Output Contact
6
SENSING AREA
2 sensing area (h =3m):
6a
presence (micromovements): (4x4)m
6b
6b
movement: (8x8)m
2
Sensing area 360°
7
DISMOUNTING
3
4
∞
lx)
