OPERATION MODE
PLAIN DMX TRANSMITTER
Whole 512 channels are transmitted; clients (Mobilight, Apestick, etc.)
need to be setup to react to the DMX stream as requested. In this case, the
setting „DMX ADDRESS" in the client setup is in effect, as well as all other
DMX related settings.
DMX REMOTE
The transmitter acts as a virtual remote control. All functions can be
controlled by DMX-channels. See below for a DMX-table.
RECEIvER
The APE FORCE ONE wireless DMX transmitter will startup as a plain DMX
receiver. Whole 512 channels are received. If a remote control signal is
received, either from a APE FORCE ONE remote control or another APE
FORCE ONE wireless DMX in DMX-Remote mode, the receiver will switch
to auto-program mode automatically. It will act like a controller with 1-32
pixels. The number of pixels can be set in the menu. See section below for
more information on DMX output.
If plain DMX is received again, the APE FORCE ONE wireless DMX switches
back to plain DMX receive mode.
INFO
SERIAL NUMBER:
XXX
FIRMWARE VERSION: Current firmware version
RF LINK:
Signal strength
FACTORY RESET
If you are confused about your settings, you can perform a factory reset.
No programs or the like will be deleted, only your personal settings.
The DMX output which is used in mode "RECEIVER" is organized as
follows.
Channels 1-96:
RGB RGB .... RGB RGB (Pixels 1-32)
Channels 97-288:
RGB 0 0 0 RGB 0 0 0 .... RGB 0 0 0 RGB 0 0 0
( 3 channels are left empty between every two pixels)
