This connector, com pliant with Intel
necting high-speed USB interface peripherals such as USB HDD, digital cameras, MP3
players, printers, modems and the like.
USB0+
Key (no pin)
Note that the pins of VCC and GND must be connected correctly to avoid possible
damage.
11
This connector is used to connect S/PDIF (Sony & Philips Digital Interconnect Format)
interface for digital audio transm ission.
12
This connector allows you to connect the front panel audio and is compliant with Intel
Front Panel I/O Connectivity Design Guide.
Downloaded from www.Manualslib.com
Front USB Connector (Yellow)
1 2
VCC
VCC
USB0- USB1-
USB1+
GND GND
USBOC
9 10
Important
S/PDIF-Out Connector or S/PDIF-In Connector
GND
SPDIF_out
VCC
SPDIF_Out SPDIF_In
Front Panel Audio Connector (Azalia Spec)
manuals search engine
I/O Connectivity Design Guide, is ideal for con-
®
Connected to SPDIF-out/
SPDIF-in connector
GND
SPDIF_in
VCC
1 2
MIC _L Ground
Presence#
MIC _R
LINE out_R MIC_JD
Front_JD NC(No pin)
LINE out_L
LINE out_JD
9 10
Installation Guide
USB 2.0 Bracket
(Optional)
SPDIF Bracket (Optional)
®
En-11
