6
MT0336
Fix using top
holes
Fix using
bottom holes
x2
712mm
TP845
Platform
x1
9 7
FA3839 FA3839
M6 x 12mm inc Spring Washer
x4
M8 x 24mm
x4
MT0336
MT0336
Fix using top
holes
TP Explorer Frame with Platform TP Explorer Frame with Platform
