TP839 Explorer Frame Inst 9187 -A 11 12:TP839 Explorer Frame Inst 9187 -A 11 12 28/11/2012 11:10 Page 13
FA3839
FA3839
x6
MT0333
959mm
M6 x 12mm
inc Spring Washer
x12
M8 x 24mm
x12
Fix using
Fix using top
Fix using
bottom holes
holes
bottom holes
TP Explorer Frame with Platform
13
