TP839 Explorer Frame Inst 9187 -A 11 12:TP839 Explorer Frame Inst 9187 -A 11 12 28/11/2012 11:10 Page 10
Low Height Assembly
x4
MT0336
712mm
Montage à faible hauteur
Montaggio per l'altezza più bassa
FA3839
FA3839
PM7074
Montaje bajo
M6 x 12mm
inc Spring Washer
25mm
x8
x6
M8 x 24mm
Halbhohe Montage
x8
Fix using top
holes
Fix using
bottom holes
For Low Height use
assembly is now
complete.
For Full Height
Fix for Low
assembly
Height
assembly
go to stage 9
only
TP Explorer Frame with Platform
10
