TP334 Single Mulitplay In4041 -F 02 13 A5:TP334 Single Mulitplay In4041 -F 02 13 A5 21/02/2013 10:21 Page 8
2
MW1007
FC8525 Swing Seat
x2
x2
2
Platform Support
986mm
1
2
M8 Hook Bolt
M6
Domed
nyloc
M6 x
25mm
Large
Washer
M8 lock nut
M8 Washer
M8 hook bolt
M8 Washer
4
M6 x 100
M6 x 100
350mm min.
Use Mallet to
firmly locate
hook bolt in
pilot hole.
8
M6 x 25mm
Large Washer
2
4
M6 Nut
M8
Lock nut
4
2
Note: Four
holes should
be present on
the bottom of
the top bar.
Forest Single Multiplay with Wavy Slide
