TP334 Single Mulitplay In4041 -F 02 13 A5:TP334 Single Mulitplay In4041 -F 02 13 A5 21/02/2013 10:21 Page 11
5
M6 Washer
M6 Dome nut
6
6
PM2001
Ground peg
M6 x 75
6
6
M6
M6 x 75
Washer
M6 Dome
nut
PM2001
Freespace/Safe Play Diagram
2m
2m
2m
2m
2m
Recommended Free Space:
The Safe Play Area refers to the zone extending 200cm (2 metres) beyond the toy on all sides and 700cm
(7 metres) above the toy. The Safe Play Area must be free from all structures, landscaping, trees and
branches, rocks, wires, sprinkler heads and other similar obstacles to safe play. Children can be seriously
injured running or colliding into such obstacles.
Forest Single Multiplay with Wavy Slide
11
