TP334 Single Mulitplay In4041 -F 02 13 A5:TP334 Single Mulitplay In4041 -F 02 13 A5 21/02/2013 10:21 Page 10
4
M6 x 25mm
M6 Lock
M6 x 35
PM8387
M4 x 22mm
Large Washer
nut
2
2
4
2
2
1
PV9590
Slide
Drill 7mm pilot holes
10
20
30
40
50
60
70
80
90
100
110
120
130
Forest Single Multiplay with Wavy Slide
10
