TP334 Single Mulitplay In4041 -F 02 13 A5:TP334 Single Mulitplay In4041 -F 02 13 A5 21/02/2013 10:21 Page 7
1
MW1069
MW1003
MW1010
6-Hole swing leg
MW1006
MW1136
Horizontal side brace
M6 x 65
6
M6 x 75
2
5
M8 x 120
Note:
Four holes should be
present on the bottom
of the top bar.
1
Top bar
1490mm
3-Hole swing leg
2
2055mm
2
2030mm
2
3-Hole swing leg
2030mm
685mm
PM2003
Bracket cover
2
M8 x 120
M8 Washer
M8 Locknut
MW1006
MW1010
1
M6 x 25mm
M8 Washer
Large Washer
10
2
M8 Lock nut
M6 Nut
5
8
No.8 x 20mm
Wood screw
M6 Washer
M6 x 65
M6 x 75
7
PM2004
90° Corner bracket
2
PM2005
10° Corner bracket
M6
Washer
1
6
PR8971
No.8 x 20mm
Branding badge
Wood screw
2
1
M6 Domed
nyloc nut
ASSEMBLY TIP
Ensure plastic
brackets are at
room temperature
MW1003
to ease assembly.
M6 Domed
nyloc nut
M6 x 25mm
Large Washer
Forest Single Multiplay with Wavy Slide
