TP active fun TP475 Montageanleitung Seite 9

TP475 Climbing Bridge In0475-B 01 14:TP475 Climbing Bridge In0475-B 01 14 20/02/2014 15:08 Page 9
5
MW1105 - Top Beam 2520mm
6
x1
M8 x 150mm Bolt x2
FA8760
Do not fully tigthen
9
4.5mm x 40mm Woodscrew x7
FA4517
M8 x 25mm
Large washer
FA7184
2
Note:
MW1105
M8 Nylon Insert
Dome Nut
FA8163
2
TP Climbing Bridge
