TP475 Climbing Bridge In0475-B 01 14:TP475 Climbing Bridge In0475-B 01 14 20/02/2014 15:08 Page 10
7
M8 x 150mm Bolt x2
FA8760
M8 x 25mm
Large washer
FA7184
2
8
M8 x 70mm Coach screw
FA8439
M8 Nylon Insert
Dome Nut
FA8163
2
M8 x 25mm Large washer
FA7184
x2
Note:
Do not fully tigthen
2
10
Note:
Now fully tigthen
bolts
ASSEMBLY TIP
Drill 3mm
Pilot Holes
TP Climbing Bridge
