MW1104 - Support Beam 985mm x1
M8 x 150mm Bolt x1
FA8760
M8 x 25mm M8 Nylon Insert
Large washer Dome Nut
FA7184
FA8163
1 1
ASSEMBLY TIP
310mm
Mark hole position with
pencil/bradel
310mm
310mm
Note:
Do not fully tigthen
