TP active fun TP475 Montageanleitung Seite 12

TP475 Climbing Bridge In0475-B 01 14:TP475 Climbing Bridge In0475-B 01 14 20/02/2014 15:08 Page 12
10
M8 x 25mm M8 Nylon Insert
Large washer
Dome Nut
M8 x 150mm Bolt x1 FA7184
FA8163
FA8760
1 1
ASSEMBLY TIP
Mark hole position with
pencil/bradel
310mm
310mm
Note:
Now fully tigthen
bolts
TP Climbing Bridge
12
