Fitting Kit
● Remove plastic screws as shown.
● Store items away in a safe place.
● Adjust the legs on the crossbar so that they
are positioned equally from the ends of the
crossbar, and the clamps engage firmly on
the body work of the vehicle.
● Locate vehicle's fixed points.
● Clamps directly to edge of roof under the
doors, pin locates in hole on vehicle on
front clamps
● Ensure the clamp pin is inserted into the
fixed point and the clamp sits flat to the
body side.
● Tighten adjusting screw to 2 Nm (1.5 ft lb)
hand tight.
9
EN
K1017W
