EN
8.
For safety purposes it is important that the hook ups are done by qualified personnel
Ensure that the hole in which the food waste disposer, located at the bottom of the sink, is appropriately
sized:
ROUND WASTE (STANDARD)
For installation of the disposer follow the insertion order of the parts in the installation kit as shown in the
figure:
21
INSTALLATION
SQUARE WASTE (OPTIONAL)
1. Plug + Waste pusher
2. Top protective gasket
3. Drain
4. Rubber gasket
5. Connection surface (sink bottom)
6. Fibre gasket
7. Fixing ring nut
8. Disposer body connection ring nut
9. Drain bottom gasket
