Spare Part Diagrams
ITEM
DESCRIPT ION
QT
4
TOP SPRING
5
O-RING
6
PISTON
7
NYLOC NUT
8
STEEL BALL
11
HANDLE
12
PUMP ROD
17
O-RING
AG12 Issue 10 © 2011
OVERHAUL
PART/ SET
Y
KIT
1
1
C7-1K
1
C7-1K
1
C7-1K
1
AC5S
1
AC42S
1
AC42S
1
C7-1K
ITEM DESCRIPT ION
2
PUMP TUBE INNER
3
PUMP TUBE OUTER
8
STEEL BALL
9
FOOT VALVE
10
SPRING
QTY
OVERHAUL
PART/ SET
KIT
1
AG21S
1
AC10S +
BS024
1
AC5S
1
AC5S
1
AC5S
