Wireless video transmitter
Precautions
• Safety
This equipment contains heat sensitive components. Maximum ambient
temperature must not exceed 35° Celsius.
Humidity in rooms where this equipment is situated must not exceed a hygrometric
level of 85 %. If you have to use your equipment outside, avoid exposing it to rain
water or to splashes. The transition from a cold environment to a hot one may cause
condensation. Allow it to dry by itself before re-starting the equipment.
In the event of prolonged absence, switch off the equipment by means of the on/off
switch. Even when switched off, certain components remain live. In order to insulate
it completely you must remove the plug from the main electricity supply.
In the event of an electrical storm, it is advisable to disconnect the equipment from
the electricity supply so as to avoid potentially damaging electrical or
electromagnetic surges. To this end, make sure that the mains plug is easily
accessible for disconnection.
Disconnect the equipment immediately if you detect a smell of burning or smoke.
Under no circumstances must you open the equipment yourself; you run the risk of
electrocution.
• Maintenance
Clean the equipment with a soft cloth and a neutral detergent. The use of solvents,
abrasive products or alcohol-based products is likely to damage the equipment.
• Regulations
This equipment must only be installed inside. Its use is restricted to private radio
transmission. Connection to a public or independent network, or to an outside aerial
is prohibited.
Under no circumstances should this appliance be put to industrial use. It is designed
solely for domestic operation.
THOMSON disclaims all responsibility in the event of use that does not comply with the
present instructions.
1
