CAUTION! Risk of detriment or damage!
The system must be protected by means of suit-
able measures against moisture, frost and heat
and also mechanical damage!
When receiving and unpacking the unit and the
supplied accessories, first check the packaging for
damage.
If damage is found which may have been caused
by dropping the system or the like:
• check the fire-extinguishing system and accesso-
ries for possible damage.
• inform the delivery company (forwarding agent)
or our customer service even if you do not find any
obvious damage to the system or its accessories.
After removing the packaging, store or install the
system according to the described installation
conditions (see section titled Installation).
Example: FLA Compact-1 Helix V1604 DS8
FLA
Compact
1
Helix V
16
04
01
DS8
Example: FLA Compact-2 Helix V2208 DS16
FLA
Compact
2
Helix V
22
08
DS16
Installation and operating instructions Wilo-FLA Compact

4 Intended use

• DIN 1988-600
• DIN 14462
• EN 1717 and EN 13077
• DIN 2000
• EU directive 98/83/EC
• Drinking water ordinance TrinkwV2001
• DVGW guidelines

5 Product information

5.1 Type key

Fire-extinguishing system
With break tank and integrated replenishment valve
Number of pumps (here with 1 pumps)
Names of the pump series
(supplied pump documentation)
Rate volume flow of the pump Q [m3/h]
Number of pump stages
Internal version indication
Adjustable control range of system according to max. working point
(8 bar in this case)
Fire-extinguishing system
With break tank and integrated replenishment valve
Number of pumps (here with 2 pumps)
Names of the pump series
(supplied pump documentation)
Rate volume flow of the pump Q [m3/h]
Number of pump stages
Adjustable control range of system according to max. working point
(16 bar in this case)
Automatic FLA Compact fire-extinguishing sys-
tems are used for supplying water to stationary,
non-automatic extinguishing systems with extin-
guishing hose connecting equipment, e.g. for fire
hose reel installations as per DIN 14462.
The fire-extinguishing system FLA Compact can
be connected directly to the public water supply.
The hydraulic separation of drinking water and fire
water is ensured by the integrated break tank with
free outlet of type AB according to EN 13077 and
EN 1717.
The following standards and guidelines should be
observed during design and installation:
Make sure that the fluid to be pumped in the sys-
tem will not corrode the materials used in the sys-
tem either chemically or mechanically and that it
does not contain any abrasive or long-fibre con-
stituents.
