22. Switches and cables must be replaced
by a professional.

General remarks

Method of use
Pour liquids in through spray nozzle. Under
pressure, the liquid is forced out in a fi ne
spray.
Painting without compressed air is best as it
avoids waste.
Use
GB
Ideal for painting woodwork, fences, indoor
and outdoor furniture, windows, doors, etc.
FOLLOWING ARE NOT SUITABLE FOR
PAINTING WITH THIS GUN.
• Materials containing abrasives.
• Glazing products.
• Materials containing various types of
paint.
• Corrosive and alkaline materials.
Use of such products can cause damage to
the gun and invalidate the guarantee.
Preparing material to be sprayed
Thin the paint to be used to the required
DIN value.
Thinners (DIN)
1. Stir thoroughly.
2. Submerge measuring cup under the
surface.
3. Lift cup and time how long it takes to
empty totally in seconds. This time
is known as the ‚DIN time' . Written as
DIN/sec.
36
Figure 1
Vibrations transferred to arm are less than
2.5 m/s².
Scale for thinning
Spray liquids:
Impregnation fl uids, primer,
varnish and lacquer
Synthetic plastic paint
and clear lacquer
Acrylic paint
Wood preservative,
pesticides, oils
Aluminium paint
Cleaning agents and
polishes
Start up
Before connecting to the mains, check that
mains electricity complies with that stated
on label attached to gun.
NOTE: Do not use with no liquid in the
container. This will ruin the pump and
invalidate the guarantee.
Thinning DIN/sec.
Unthinned – 30
15 – 30
20 – 30
Unthinned – (Max. 30)
15 – 30
Unthinned – (Max. 30)
