6.7

Data import

To be able to import the series of measurements from the PCE-GM 75 to the software, the meter
must be connected to the USB port of the PC first. Windows recognises the PCE-GM 75 as a
removable storage device.
Just click on the icon to open a dialogue for selecting the storage location. Now select the
text file on the PCE-GM 75.
After confirming your selection by clicking on the "Open" button, the measuring data will be
imported into the software.
6.8

Export of series of measurements

Via the icon of the toolbar, the entire content of an individual series of measurements can be
exported in CSV format.
If required, the separator can be changed via the settings dialogue
6.9

Loading and saving series of measurements

A series of measurements can be loaded via the
the desired PCE file into the list on the left.
The series of measurements can be saved via the
icon or by drag and drop, i. e. by dragging
icon.
