2.3.3 External Keyboard

The optional displaced keyboard comprises all functions described above. Keys are
lettered with the use of the same symbols.
Exceptions:
•
Function 'ABORT': Start the Abort function by using the top left [Esc] key.
•
Function 'Acknowledge event'
•
Function 'Display test'

2.4 Scale Specific Control

The scale function keys have different meanings depending upon the function variant
activated.

2.4.1 DISOMAT F

This function variant activates the compatibility to the parent DISOMAT F.
Key(s):
F1: Print

2.4.2 Filling Scale

2.4.2.1 Function Keys

With the Filling Scale, the function keys are assigned as follows:
BV-H2322 AA 0630
- 44 -
'Start Filling'
F1 key: 'Start'
'Stop Filling'
F2 key: 'Stop'
Resume filling with F1 = Start.
'Select material, enter setpoint'
F3 key: 'MatSet'
'Print Sub-total'
F4 key: 'PrintBal'
'Abort Filling'
F5 key: 'Abort'
'Print Total/Clear Balance'
F6 key: 'PrinTot'
