Filter control
CONT-A/24 Control box with timer for valves MDB; no
filter monitoring.
CONT-B/24 Control box with timer for valves MDB; incl.
CONT-B/64 filter monitoring device. Pressure gauge
included.
CONT-BF/24 Control box with timer for valves MDB; incl.
CONT-BF/64 filter monitoring device. Pressure gauge
and pre-wired fan starter contactor
included.
CONT-C/24 Control box for valves MDB; pressure
CONT-C/64 controlled automatic filter cleaning.
CONT-CF/24 Control box for valves MDB; pressure
controlled automatic filter cleaning.
Pre-wired fan starter contactor included.
Fan control
MSA range Motor starter (star-delta switch) for
connection to a potential-free contact
Options:
- RC-MSA - Remote control
- RC-MSA/T - Remote control with timer
VFD range Frequency inverter incl. main switch
Options:
- PT-1000 - Pressure transmitter 0-1000 Pa for use in
Push-Pull systems
- PT-2500 - Pressure transmitter 0-2500 Pa for use in
multiple arm systems
Filter + fan control
SCP-MDB range System control panel with frequency
inverter for SIF fan with MDB
CB-MDB/PMD Control box with pressure sensor for use
with SCP-MDB
Options:
- PT-1000 - Pressure transmitter 0-1000 Pa for use in
Push-Pull systems
- PT-2500 - Pressure transmitter 0-2500 Pa for use in
multiple arm systems
ControlGo Intelligent control panel with HMI for basic
fan/filter control
ControlPro Intelligent control panel with HMI with
extensive feature package for fan/filter
control; remote access via network
1.4 options and accessories
The following products are available as an option and/or
accessory:
Type Description
DB-TROLLEY/80 dustbin trolley
BPF prefilter module
CAR-KIT compressed air regulator
MRD-315 manual damper with cut-off blade to
MRD-400 regulate the airflow
MRD-500
PRECO-N precoat material for use with filter
cartridges CART-D, -C and -E (refer to
section 1.3.1)
0000100513/150417/B MDB
1.5

Technical specifications

general
Material of housing
- steel grade
- steel grade no.
Capacity of dustbin
Noise level
Max. height
Max. width
Compressed air system
Contents compressed air
tank; filter module:
- MDB-BM/2
- MDB-BM/4
Required compressed air
quality
Required pressure
Compressed air
connection
Compressed air
consumption
Electrical data
Input voltage for
magnetic valves
Approvals and certifications
CE
MDB + CART-PTFE/10
MDB + CART-PTFE/15
For details about the welding fume class related to the
product type, the number of filter cartridges and the filter
surface, refer to Table I on page 82.
Refer to the available product data sheet for
detailed product specifications.
1.6 Dimensions
For dimensions of the separate filter modules and the frame,
refer to Fig. I on page 83.
Refer to the available product data sheet for
dimensions of entire MDB systems.
1.7 Ambient and process conditions
Process temperature:
- min.
- nom.
- max.
Max. relative humidity
Storage conditions
Outdoor use allowed
electro-zinc coated steel
(according to DIN EN 10152)
DC01+ZE
1.0330
80 litres (21 gallon)
depends on the selected
extraction fan
4800 mm (189 in.) (frame + 4
filter modules MDB-BM/4)
4800 mm (189 in.) (4 filter
modules MDB-BM/4 + inlet/
outlet modules)
approx.:
- 10 litres (2.5 gallon)
- 20 litres (5 gallon)
dry and oil-free according to
ISO 8573-3 class 6
4-5 bar (60-75 PSI)
push-in fitting:
- in: ⅜ in.
- out: 12 mm
40-50 nl/pulse (1.4-1.8 ft³/
pulse)
24 VAC
MDB = IFA-W3 certified;
separation performance >99%
5°C (41°F)
20°C (68°F)
70°C (158°F)
90%
5-45°C (41-113°F)
relative humidity max. 80%
yes
