Spaun SMS serie Technische Hinweise Seite 12

Technical advice for the multiswitches
• SMS 9940 NF
• SMK 9940 F
• SMK 9960 F
!
104012 / 04.00
It is important that you read this manual completely.
Do not install the multiswitches in humid places.
Allow adquate ventlation.
Specified for the temperature range
-20° C ... + 50° C (253 K ... 323 K).
Select the correct LNB remote voltage.
Connect the LNBs as described on multiswitches label.
The trunklines must be terminated with DC blocked
terminators (SMS 9940 NF and SMK 99xx F only).
Connect to mains supply, adjust the input levels accordingly.
• SMS 9400 NF
• SMS 9600 NF
• SMS 9800 NF
